Silicon wafers are high-purity substrates widely used in SEM imaging, material characterization, and semiconductor research. With a smooth, defect-free surface, they provide excellent stability for thin film deposition, nanofabrication, and microstructural analysis. Ideal as SEM substrates or for use in advanced electronic and photonic research, silicon wafers ensure reliable performance and reproducible results.
